Energy saving transformation of R15K551.1 coupler

Transformation method 1: direct coupling of coupler, variable frequency speed regulation, external lubricating oil station

新币彩票Transformation mode two: change gear box and front pump to transform and configure new speed motor

新币彩票Reconstruction method three: retaining the coupling function, external oil station to restore the oil supply system

新币彩票The reform contents include: the field surveying and mapping before the project transformation, the reform scheme design, the implementation of the overall project transformation, and the commissioning and operation after the transformation

新币彩票The substance of the coupler is the combination of a centrifugal pump and a turbine. It is mainly composed of the input shaft, the output shaft, the pump wheel, the turbine, the outer light, the auxiliary chamber and the safety protection device. The input shaft is connected with the power machine, and the other end is connected to the output shaft end of pump Tuo: connected to the turbine, and the other end of the working machine. The pump wheel and the turbine are arranged symmetrically, and a certain number of blades are arranged in the wheel. The shell and the pump wheel is fixedly connected into the sealed cavity, filling working fluid to transfer the power; when the prime mover driven by the input shaft rotary pump wheel, filling in the working chamber of the working liquid by centrifugal force and leaves work round by the pump wheel entrance small radius are accelerated by pressure into the larger radius of the pump impeller outlet at the same time, the momentum of the liquid that generate incremental coupling pump wheel input mechanical energy is transformed into kinetic energy of liquid: when working liquid carrying the kinetic energy of liquid from the pump impeller outlet rushed across the turbine, the flow channel is formed along the vortex blade Tuo the centripetal flow, while the release of the liquid kinetic energy is converted into mechanical energy the driving turbine rotate and drive the work load. In this way, the liquid circulate in the working chamber again and again, so the output and input can be flexibly linked by liquid kinetic energy without any direct mechanical connection. Baoding Hengsheng hydraulic coupler manufacturing company specializing in the production of various types of yox, yox production with light load starting, overload protection, to reduce the impact, isolation of torsional vibration, coordination of multi machine drive, flexible braking and energy balance function, can effectively protect the motor and the working machine is not damaged. Widely used in mining, metallurgy, coal, electricity, oil, leather, construction, building materials, chemical industry, textile, light industry, woodworking, transportation and other industries.
